BASE SPECIFICATION
|
BRAND |
JB MICROSCOPE |
|
Vertical post height |
500mm |
|
Focus distance |
160mm |
|
Microscope body holder |
φ76mm |
|
Stage plate |
95x5mm black, white contrast plate |
|
Base |
320x308x316mm |
|
Focus |
Coaxial Coarse & Fine |
|
Coarse Focus Distance per Rotation |
23mm |
|
Fine Focus Distance per Rotation |
0.56mm |
|
Focusing Knob |
Tightness Adjustable |
|
Material |
Metal |
|
Color |
White |
Technical Parameters
|
Magnification |
7X-60X Stereo Zoom. 3.5X-200X with Optional lens |
|
Eyepiece |
WF10X/22mm high eye- Point Wide field eyepiece, convenience for eye -wearing observers WF 15X/15mm, WF20 X10mm, WF25x/9mm eyepiece is optional. |
|
Microscope Head |
Binocular Trinocular head, 45°inclined, 360° rotatable. interpupillary distance: 54-76mm. Diopter adjustable on both tubes. |
|
Objective |
0.7X-6X stereo zoom, Zoom Ratio: 8.6:1 |
|
Auxiliary Objective |
0.5X, 0.3X, 0.7X, 2X |
|
Stands |
various stand can be configured based on requirement for more options, please refer to page “microscope stand” |
|
illumination |
5V3W up-down led illuminated/Led ring lamp, Refer to page “External illumination |
|
Camera adapter |
phototube, C -mount for Camera |
|
Eyepiece |
Standard Configuration Magnification |
Working Distance :120mm
|
|
WF10X/22mm |
7x 60x |
31.4 3.7 |
|
WF20X10mm |
14x 120x |
14.3 2 |
