Specification:
Focal Length: 10-40mm
Sensor Spec:1/1.7”CCD/CMOS 5.7×7.6,9.5 1/1.8”CCD/CMOS 5.36×7.15,8.93
Max Image Circle: Φ9.6
Back Focal Length: 8.17mm~9.34mm (In air)
Mount: C Mount (1-32UNF)
FNO: F1.3
Iris: Manual Iris / DC & P-iris optional
(F.O.V.) (D/H/V): 1/1.7” 52.7°~14.2°/42°~11.4°/31.3°~8.6°
1/1.8” 50°~13.8°/39.5°~10.7°/29.5°~8.1 °
M.O.D: 1m
Working Distance: ∞
Effective Diameter: Φ45.6mm Front
Φ15.3mm Back
Lens construction: 17-12
TV Distortion: 1/1.7” -5%W~0.19%T
1/1.8” -4.5%W~0.15%T
Resolution: 12mp 4K
Relative illumination: >40%
Max Chief Ray Angle: 4°
TTL: 109.83mm (in air)
Dimension: Φ54×95.62mm
